Stepper motor

See this article, you may have some understanding of the stepper motor, then the working principle of the stepper motor is no longer repeated. If you want to know the price of the stepper motor, click the blue font to enter the corresponding page; If you want to know how to connect the stepper motor controller or the stepper motor driver wiring method, stepper motor selection, you can contact our online customer service or directly call the company's free technical service hotline: 400-960-1069, about the stepper motor common problems, such as: What causes the stepper motor to be hot, how to eliminate the interference of the stepper motor, why the stepper motor will lose the step, how to improve the speed of the stepper motor, how to judge whether the stepper motor has been damaged, the torque and power conversion method, how to solve the noise problem of the stepper motor, the difference between the stepper motor and the servo motor, etc., technical engineers can also give you quick and accurate answers.

Next, take you to a macro understanding of the stepper motor from the level of non-technical principles

From the current to divide: DC and AC two

From the number of phases: two phase (step Angle 1.8°), three phase (step Angle 1.2°), five phase (step Angle 0.72°) Note: no subdivision or deceleration device is involved

From the control mode to divide: open loop, closed loop

From the output shaft: single shaft, double shaft (main application and synchronous drive)

From the application function: hybrid stepper motor, linear (ball screw) motor, deceleration motor, stepper motor with brake, hollow shaft stepper motor (convenient threading, threading), integrated stepper motor, absolute encoder stepper motor, waterproof stepper motor

From the flange size: 20mm, 28mm, 35mm, 42mm, 57mm, 60mm, 86mm, 110mm, 130mm(the list here is commonly used, the use of smaller or larger are basically changed to other drives; Generally, the larger the flange size, the greater the relative output torque)

As an executive component, it must be required to receive instructions to run, here we have to mention the stepper motor drive (directly with PLC control can also be achieved, but relatively troublesome), the engineer will recommend you to use a matching drive after selecting a good stepper motor, of course, a motor can be matched with different modes of drive, The key is the application requirements of the equipment, detailed requirements, generally have more than 3 years of engineers can accurately help you configure.

If the above information does not solve the knowledge you want to know, you can give us a message or telephone consultation, we will give you a satisfactory answer!
